Solar Charge Controller 12V 24V 10A 20A 30A Solar Controller Solar Panel Battery Controller Regulator Dual USB LCD Display
Product selling points:
1. Use high-quality materials, durable
2. Industrial master chip
3. Large screen LCD display; Charging and discharging current display; Query of accumulated power generation and discharge; Temperature display; Optical control+delay control; Adjustable charging and discharging parameters; With power off memory and other functions
4. Built in overcurrent, short circuit protection, open circuit protection, reverse connection protection, all of which are self repairing and will not damage the controller
5. Wide application range
Parameters:
Material: ABS+PC
System voltage: 12V24V automatic adaptation
Rated charging current (optional): 10A/20A/30A
Maximum photovoltaic voltage: 23V for 12V batteries; 46V for 24V battery
Boost charging voltage: 14.4V
Floating voltage: 13.7V (default, adjustable)
Discharge cut-off voltage: 10.7V (default, adjustable)
Discharge recovery voltage: 126V (default, adjustable)
Charging recovery voltage: 13V
Photovoltaic panel with light control opening threshold: 8V (there is delay in light control opening)
USB output: 2 USB outputs, 5V/2.5A (maximum)
Standby current:<10mA
Operating temperature: - 35 -+60 ℃
Suggestions for safe use:
1. The controller automatically recognizes 12V24V. When installing for the first time, make sure that the battery has enough voltage so that the controller can identify the correct battery type.
2. Install the controller as close to the battery as possible to avoid voltage drop caused by too long wire, which affects normal voltage judgment.
3. This controller is only applicable to various lead-acid batteries (including openings, seals, gel, etc.).
4. The controller can only use the photovoltaic panel as the charging source. Do not use DC or other power supply as charging power supply.
5. The controller will generate heat during operation. Please pay attention to installing the controller on a flat and well ventilated surface.
Package List:
Solar controller * 1
